Listing details & specifications

Specifications are reproduced from the listing. Confirm the machine’s identity, condition, configuration and included attachments with our team.

SKU A24 Hours: 1600 (18 October 2023) Specifications: Boom width: 90 feet ( 27.43 meters) Capacity: polymer Hydraulic tread adjustment: yes Hydraulic front-wheel-drive assist: yes Poly tank capacity: 660 gallons ( 2498.37 liters) Section control: yes Tires: 380 Hydraulic tread adjustment: yes GPS Outback: yes Dimensions: Length: 8,81 m Height: 3,68 m Width (wheels set inward): 3,00 m Wheelbase: 3,99 m Clearance: 1,22 m Engine: Make: Perkins Model: 1106D Power: 174 hp (130 kW) Capacity: 6,6 L Torque: 696 N·m Transmission: Type: Caterpillar PG 115 Powershift Number of gears: 6 forward, 2 reverse Maximum speed: 44,3 km/h Spraying system: Solution tank capacity: 2 744 L Tank material: polyethylene Rinse tank capacity: 246 L Handwash tank capacity: absent Foam tank capacity: optional Chemical eductor tank capacity: 17 L (optional) Suspension: Front: linear springs Rear: hydraulic Wheels: Standard for row spacing: Front: 320/85 R38 Rear: 380/80 R46 Optional for row spacing: Front: 380/80 R38 Rear: 320/90 R46 Flotation: Front: 540/65 R24 Rear: 480/80 R46 Optional flotation: Rear: 620/70 R42 Overall sprayer dimensions with booms unfolded: Boom width: from 18,3 m to 27,4 m Nozzle spacing: 25,4 cm or 50,8 cm Weight: With smallest booms: 3 700 kg With medium booms: 3 700 kg With largest booms: no booms over 27,4 m Additional features: Cab size: 5,04 m² Track width: from 2,23 m to 3,05 m Turning radius: 5,44 m Steering system: 2WS
