Stock ID T20
2018 Case IH Magnum 280 AFS
This is a third-party equipment listing. D.E. Agora Agricultural Equipment provides sourcing services and confirms availability and current price before quoting.
Listing details & specifications
Specifications are reproduced from the listing. Confirm the machine’s identity, condition, configuration and included attachments with our team.
SKU T20 Hours: 4735 (4900 estimated) Power: 280 hp Cab type: Cab Drive type: MFWD Transmission type: IVT Guidance ready: Yes Steering receiver: Yes Control display: Yes Rear PTO: 1000 Dual tires: Yes Tire width: Wide Tractor Case IH Magnum 280 AFS Connect 2018 model year is a powerful agricultural tractor designed for high productivity and efficiency. Here are its main specifications: Engine: Type: 6-cylinder diesel engine FPT with capacity 8,7 liters. Rated power: 280 hp (208,8 kW) at 2 000 rpm. Maximum power: 315 hp (234,9 kW) at 1 800 rpm. PTO power: 235 hp (175,2 kW) at 2 000 rpm. Transmission: Type: Fully automatic transmission CVXDrive™. Number of gears: 19 forward and 4 reverse. Maximum speed: 40 km/h. Dimensions and weight: Wheelbase: 3 050 mm. Weight: 12 973 kg. Tire sizes: Front—420/85R34, rear—480/80R50. Hydraulic system: Type: Pressure- and flow-compensated system (PFC). Pump capacity: 162 L/min. Number of hydraulic outlets: 4 standard and 2 additional. Lift capacity: Rear three-point hitch: to 6 350 kg. Front three-point hitch: optionally up to 4 275 kg. Cab: Type: Spacious cab Surveyor™ with suspension. Equipment: Air conditioning, heated and ventilated seat, advanced information systems. Additional features: System AFS Connect™: for remote tractor monitoring and control. Automatic guidance system: optionally available to improve operating accuracy and efficiency. This tractor is ideal for heavy agricultural work, providing high productivity and operator comfort.
